This fast growing family of heavy dumpers wagons is the newest member in our product sortiment. At present, we produce in sizes from 6000 - 15 000 kg, all with 4 mm Hardox in the body of the loadingbed in order to stand rough handling for many years. Well equipped products are always appreciated by our customers so listen to this list of standard equipment:
The only extra option available for these programme is extra high sidewalls.
| Heavy Dumpers | K-Schakt 7.0 | K-Schakt 8.0 | K-Schakt 10.0 | K-Schakt 11.0 | K-Schakt 13.0 |
|---|---|---|---|---|---|
| TotalLength mm | 5200 | 5200 | 5830 | 5200 | 5820 |
| Total Width mm | 2400 | 2400 | 2500 | 2400 | 2500 |
| Bed Dimension | 3650*2100*580 | 3650*2100*575 | 4273*2330*580 | 4300*2350*575 | 4270*2300*675 |
| Volume, M3 | 4,4 | 4,4 | 4,4 | 6 | 6 |
| Tipping Angle, 0 | 55 | 55 | 55 | 55 | 58 |
| Net Weight kg | 1300 | 1696 | 2190 | 2300 | 2990 |
| Max Load kg | 7000 | 8000 | 10000 | 11000 | 13000 |
| Total Weight kg | 8300 | 9696 | 12190 | 13300 | 15990 |
| Wheel | 400/60 15,5 pr |
400/60 15,5 14pr Boggi |
400/60 15,5 14pr Boggi |
500/50 17 Boggi 4-wheel brakes |
500/50 17 Boggi 4-whell brakes |
| Speed km/h | 40 | 40 | 40 | 40 | 40 |
